◆52 Gas Regulator/Model:GT-018-52
Stall-sized pressure regulator is applicable to all welding cuts.The design of double pressure gage make it easy to read the storage pressure and working pressure. The main body is forged and fashioned from high-quality brass and the upper cover is manufactured from aluminum alloy and spray-finished ; and for 50mm pressure gauge ,external relief valves are equipped and sintered bronze filter is in stalled at the air inlet.
Model | Applicable Gas | Max. Input Pressure | Max. Output Pressure | Inlet | Outlet |
GT-018-52 | OXYGEN | 270 bar | 10 bar | G 5/8 | G3/8 |
ACETYLENE | 25 bar | 1.5 bar | G 5/8-LH | G3/8-LH | |
PROPANE | 1.5 bar | 7/8-14LH | G3/8-LH |
