◆52 Gas Regulator/Model:GT-002-70A
Medium-sized regulator is suitable for use in manufacturing,construction, and installation and other field.The design of double pressure gage make it easy to read the storage pressure and working pressure.The psi-kpa double scale reading has a wider range of application and display more visually. The body is made by foreign and pressing quality brass.The upper cover is made by pressing copper with high-strength zinc alloy.The surface adopts q235 with chrome plating.It’s equipped with an outer relief valve.A sintered bronze filter is in stalled at the air inlet.
Model | Applicable Gas | Max. Input Pressure | Max. Output Pressure | Flow | Inlet | Outlet |
GT-002-70A | OXYGEN | 2400Psi | 120Psi | 30m³/h | CGA540 | 9/16-18UNF |
ACETYLENE | 240Psi | 15Psi | 5m³/h | CGA300 | 9/16-18UNF-LH | |
PROPANE | 240Psi | 15Psi | 5m³/h | CGA510 | 9/16-18UNF-LH | |
AR | 2400Psi | 120Psi | 30m³/h | CGA580 | 9/16-18UNF |
