We have provided many kinds of stainless steel welding wire for long time and have win praise from foreign customers for its good quality.
◆ Product Intriduction:
Product | Mechanical Properties of deposited metal | Chemical Composition | |||||||
AWS | Tensile Strength /Mpa | Elongation % | C | Si | Mn | Cr | Ni | Cu | Mo |
580 | 43 | 0.040 | 0.51 | 1.27 | 18.30 | 9.40 | 0.03 | 0.01 | |
ER307 | 600 | 42 | 0.083 | 0.45 | 4.52 | 20.21 | 9.38 | 0.03 | 1.02 |
ER307Si | 605 | 41 | 0.074 | 0.72 | 6.79 | 18.83 | 8.23 | 0.02 | 0.08 |
ER308 | 590 | 41 | 0.039 | 0.35 | 1.75 | 20.12 | 9.47 | 0.03 | 0.01 |
ER308L | 550 | 42 | 0.025 | 0.43 | 1.63 | 20.05 | 10.20 | 0.02 | 0.02 |
ER308LSi | 560 | 41 | 0.024 | 0.75 | 1.98 | 20.70 | 10.20 | 0.05 | 0.02 |
ER309 | 610 | 40 | 0.078 | 0.42 | 1.66 | 24.25 | 13.10 | 0.04 | 0.02 |
ER309L | 570 | 42 | 0.026 | 0.38 | 1.78 | 23.65 | 12.85 | 0.03 | 0.01 |
ER309LSi | 580 | 39 | 0.024 | 0.73 | 2.05 | 23.94 | 13.83 | 0.04 | 0.02 |
ER310 | 605 | 41 | 0.088 | 0.40 | 2.03 | 27.41 | 21.75 | 0.05 | 0.02 |
ER316 | 580 | 39 | 0.049 | 0.37 | 1.75 | 19.01 | 12.73 | 0.04 | 2.48 |
ER316L | 560 | 40 | 0.023 | 0.39 | 1.93 | 19.32 | 12.42 | 0.06 | 2.57 |
ER316LSi | 570 | 38 | 0.024 | 0.73 | 1.61 | 18.72 | 11.54 | 0.07 | 2.31 |
ER2209 | 770 | 30 | 0.01 | 0.41 | 1.7 | 23.4 | 8.9 | 1.5(N) | 3.2 |
Item | Size | Packing Available |
MIG | 0.8-1.6mm | 1kg/D100, 5kg/D200, 12.5kg/D300, 15kg/D300 Pail Packing:100kg/drum, 250kg/drum |
TIG | 1.0-4.0mm | Length: 1000mm, stamped. 2kg/tube, 5kg/tube |
Coils | 2.4-4.0mm | 25kg/coil, 100kg/coil |
