IGBT Inverter MIG Welding Machine
IGBT Inverter MIG Welding Machine
◆IGBT inverter technology
◆Over heating and current prorection
◆Gas/no gas
◆Easy operation
Main technical data：
Type | MIG-275S | MIG-275T |
Power Supply | AC220V 50/60Hz | AC380V×3 50/60Hz |
Rated Input Power | 9.8KVA | 9.8KVA |
Rated Input Current | 45A | 18A |
Rated None Loading Voltage | 65V | 65V |
Range of Current regulation | 10-280A | 10-280A |
Range of Voltage regulation | 14.5-28V | 14.5-28V |
Duty Circle | 40% | 60% |
Power Factor | >0.8 | >0.8 |
| For wire Diameter | 0.8-1.2 | 0.8-1.2 |
Feeder Type | Dual Drive | Dual Drive |
Weight of machine | 33kg | 37kg |
Size: L*W*H | 550×280×530mm | 580×317×665mm |
