IGBT Digital Single Pulse MIG Machine (Build-in)
IGBT Digital Single Pulse MIG Machine (Build-in)
◆DSP Digital cotrol system
◆With unified adjusting function
◆Special four steps function
◆Both Single phase and three phase are available
Type | SPA-305S | SPA-305T |
Power Supply | AC 1x220V 50/60Hz | AC3x380V×3 50/60Hz |
Rated Input Power | 9.8KVA | 9.8KVA |
Rated Input Current | 45A | 18A |
Rated None Loading Voltage | 65V | 65V |
Range of Current regulation | 10-280A | 10-280 |
Range of Voltage regulation | 14.5-28V | 14.5-28V |
Duty Circle | 60% @ 250A | 60% @ 280A |
| >0.8 | >0.8 |
| 0.8-1.2 | 0.8-1.2 |
Welding Application | MS.,SS., Al., Copper | MS.,SS., Al., Copper |
Weight of machine | 45kg | 48kg |
Size: L*W*H | 830×430×710mm | 830×430×710mm |
