IGBT Digital Single Pulse MIG Machine (Build-in)
IGBT Digital Single Pulse MIG Machine (Build-in)
1.DSP Digital cotrol system, stable input, precise feeding, high capaibity for anti-voltage fluctation.
2.IGBT inverter technology, stable welding process and excellet welding seam.
3.With unified adjusting function,Built-in welding expert database, and
Automatic intelligent parameter combination.
4.Good performance for thin sheet welding, suitable for welding various kinds of aluminum alloy, stainless steel, copper alloy etc, less welding spartter.
5.Special four steps function, suitable for high conductivity metal, arc start and arc end can be adjusted, perfect welding quality.
6. Small size, light weight, convenient to carry, high stability, electricity saving.
7. Both Single phase and three phase are available.
Main technical data：
Type | SPA-280S | SPA-280T |
Power Supply | AC 1x220V 50/60Hz | AC3x380V×3 50/60Hz |
Rated Input Power | 9.8KVA | 9.8KVA |
Rated Input Current | 45A | 18A |
Rated None Loading Voltage | 65V | 65V |
Range of Current regulation | 10-280A | 10-280 |
Range of Voltage regulation | 14.5-28V | 14.5-28V |
Duty Circle | 60% @ 250A | 60% @ 280A |
| >0.8 | >0.8 |
| 0.8-1.2 | 0.8-1.2 |
Welding Application | MS.,SS., Al., Copper | MS.,SS., Al., Copper |
Weight of machine | 34kg | 37kg |
Size: L*W*H | 560×280×620mm | 560×280×620mm |
