TP-205 is high quality water cooling plasma power source for CNC cutting which has high pierce capability and can achieve high verticality. TP-205 adopts the full-bridge soft-switching technology, current can be adjustable between 35A-200A steplessly, it can make cutting operation more controllable It is heavy duty, 100% duty circle, and it has built in multi protections for over current, over voltage, over air-pressure, over temperature etc, allows you to work 24 hours continuously.
Technical Parameters
Model | Unit | TP-205 | EMC-400M |
Rated Input Voltage | V | 3x380(50Hz) +/- 10% | |
Rated Input Power | KVA | 57 | 78 |
Cutting Current | A | 300 | 400 |
Duty Circle | - | 100% | 100% |
Cutting Thickness | mm | 32 | 35 |
Pierce Thickness | mm | 32 | 35 |
Quality Cutting | mm | 50 | 60 |
Max. Cutting | mm | 60 | 70 |
Working Gas | - | Air/N2 | Air/N2 |
Gas Volume | L/min | 150 | 150 |
Working Gas Pressure | Mpa | 0.7 | 0.7 |
Cooling Method | - | Water | Water |
Weight of Machine | kg | 130 | 150 |
Size of Machine | cm | 83x47x90 | 83x47x90 |
【HC6002 part name and code】
Cutting Method | Current (A) | Electrode | Nozzle | Protective Cap | Water Tube | Copper Sleeve | Gas Diffuser | Copper Cap | Shield Cap |
Water Mist Cutting | 70-200 200-300 300-400 | 621040 | 622020 622030 622040 | 623140 | 624060 | 625060 | 626040 | 627060 | 628060 |
