◆Features
1. Steel square tube welded beam to ensure solid and stable; Precision process prevent the deformation. Steel square tube machine support, solid and easy to adjust.
2. Transmit is through gearing rack, using the precision planetary reducer made in Taiwan. The cylinder rail is also made in Taiwan.
3. Control system is made by Sino-USA joint venture, 7’’ LCD monitor, English operation manual available.
High precision Step moto and diver system ensure the machine’s stability during high speed running.
4. Three options available:Plasma Only, Flame Only and Plasma & Flame.
Technical Parameter | ||
Type | ZYNC-XLM3222 | ZYNC-XLM4222 |
Machine Size | 4000x3200mm | 5000x3200mm |
Cutting Scope | 3200x2200mm | 4200x2200mm |
Cutting Method | Plasma/Flame | |
Effective Lift Distance | 120mm | |
Maximum Idle Speed | 18000mm/min | |
Cutting Speed | 15000mm/min | |
Operation Precision | <0.1mm | |
THC Controlling | Plasma using THC control system/Flame using motor control | |
Maximum Cutting Thickness | 1. Plasma Cutting thickness according to power source, suggested thickness less than 20mm. 2. Flame cutting thickness:5-150mm | |
Cutting Gas | 1. Plasma:Air 2. Flame:Oxygen+ Fuel Gas | |
Gas Pressure | 0.4-0.8Mpa | |
Machine Input Power Supply | 220V 50HZ | |
Nest Software | FASTCAM | |
